Spectral

#

22^nd May 2025
Prepared By: perrythepwner
Challenge Author(s): perrythepwner
Difficulty: Easy

TLDR

#

The VCNK.sol contract acts as a power plant, delivering on-demand power to arbitrary contracts that implement the vcnkCompatibleReceiver interface. The VCNK contract is missing the Checks-Effects-Interactions (CEI) pattern in requestPowerDelivery, and its reentrancy guard (require(msg.sender == tx.origin)) is obsolete after the EVM Pectra upgrade (EIP-3074 / EIP-7702). An attacker can therefore bypass the guard via a delegated EOA, recursively call requestPowerDelivery in their deliverEnergy callback, drive the control unit’s capacity below the fail-safe threshold, and trigger Emergency Mode.

Description

#

A new nuclear power plant called “VCNK” has been built in Volnaya, and the dominance of the energy lobby is now stronger than ever. You have been assigned to Operation “Blockout” and your mission is to find a way to disrupt the power plant to slow them down. See you in the dark!

Skills Required

#

• Basic understanding of Solidity and smart contracts
• Interaction with smart contracts
• Basic understanding of reentrancy attacks

Skills Learned

#

• Reentrancy attacks after Pectra upgrade and EIP-7702

Analyzing the Source Code

#

Setup.sol

#

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.29;

import { VCNK } from "./VCNK.sol";

contract Setup {
    VCNK public TARGET;

    event DeployedTarget(address at);

    constructor() {
        TARGET = new VCNK();
        emit DeployedTarget(address(TARGET));
    }

    function isSolved() public view returns (bool) {
        uint8 CU_STATUS_EMERGENCY = 3;
        (uint8 status, , , ) = TARGET.controlUnit();
        return status == CU_STATUS_EMERGENCY;
    }
}

The Setup.sol contract, as common for blockchain challenges, simply instantiates a fresh VCNK contract and implements the isSolved function used by the server to check if the challenge’s solve criteria are met. The requirements are that the ControlUnit status of the VCNK contract is set to CU_STATUS_EMERGENCY.

VCNK.sol

#

Prague/Electra (Pectra) hardfork

#

First of all, an important detail is that in the foundry.toml file, the VCNK contract is set to be deployed with the “Prague” hardfork.

[profile.default]
src = "src"
out = "out"
libs = ["lib"]
evm_version = "prague"

“Prague” and “Electra” were supposed to be two different upgrades for Ethereum, but they were merged into one upgrade called “Pectra”. The Pectra upgrade includes updates to both the execution layer and the consensus layer of the Ethereum network. One of the most relevant changes in this upgrade is the implementation of EIP-7702, which allows user accounts (EOA) to be extended with smart contract code, effectively allowing them to act as smart contracts and therefore make use of some the Account Abstraction concepts. For example:

• Transaction Batching: EOAs can now batch multiple operations into a single transaction, reducing gas fees and improving efficiency.
• Gas sponsorship (meta-txs): Third parties (dApps, relayers, or service providers) can pay gas on behalf of end users. Account X signs an authorization so that account Y’s EOA can execute code and have its gas fees covered without Y holding ETH.
• Programmable Wallets: EOAs can now have programmable logic, allowing for more complex interactions, such as multi-signature wallets, time-locked accounts, and more.

More details about the Pectra upgrade: https://ethereum.org/en/roadmap/pectra/

Allowing EOAs to execute smart contract code means that the msg.sender of a transaction can now be the EOA itself, which has never been possible before. Therefore, the Pectra upgrade broke some past assumptions used for example for security measures, such as reentrancy guards of the form require(msg.sender == tx.origin). While that pattern was a valid (and cheap, because storing lock-like variables in global storage is expensive) reentrancy guard before the Pectra upgrade, it is now useless. This challenge focuses on this aspect of the Pectra upgrade, and how it can be concretely exploited.

Core Logic

#

Regarding the VCNK contract, the code mainly revolves around a ControlUnit struct stored in contract state, along with a per-address Gateway struct mapping. The ControlUnit holds the kernel status and state:

• ControlUnit.currentCapacity: holds the current power capacity of the plant (how much power can be delivered). After each successful power delivery, this value is reset to MAX_CAPACITY. If that value drops below FAILSAFE_THRESHOLD, the failSafeMonitor modifier sets the ControlUnit status to Emergency Mode.
• ControlUnit.status: indicates the current status of the control unit (idle, delivering, emergency).
• ControlUnit.allocatedAllowance: the total amount of power that the overall gateways can request.

The contract logic requires users to register via the registerGateway and pay a 20 ETH fee, in order to register an arbitrary Gateway contract address into the gateways mapping. After that, they can top up their individual quotas (up to 10 ETH) via requestQuotaIncrease.

The heart of the protocol is requestPowerDelivery. This function first checks that the caller’s gateway is in the idle state and that the requested amount does not exceed its current quota. It then emits a delivery request event, sets the control unit status to delivering, and subtracts the desired amount from controlUnit.currentCapacity. Only after these steps does it perform the external call to vcnkCompatibleReceiver(_receiver).deliverEnergy(_amount). As already mentioned, the vcnkCompatibleReceiver contract can be arbitrary, meaning we have execution flow control. Only after the external deliverEnergy callback execution, the gateway.totalUsage is updated with the requested amount, and the controlUnit.currentCapacity is reset back to MAX_CAPACITY. This is a common missing Checks-Effects-Interactions (CEI) pattern, potentially leading to reentrancy vulnerabilities.

As already mentioned, the circuitBreaker modifier, supposed to break reentrancy attempts, is basically useless after the Pectra upgrade, and because the external interaction happens before the updates to the gateway’s usage and before re-setting state, an attacker can reenter requestPowerDelivery during the deliverEnergy callback to repeatedly drain capacity and trigger Emergency Mode on the CU.

Exploitation

#

While the main attack vector is a textbook reentrancy exploit, the EIP-7702 EOA->Contract delegation might not be so straightforward, especially in these early stages of the upgrade. Moreover, at the time of writing, the Foundry’s signDelegation cheatcode seems broken (I still provided the wannabe foundry exploit here because I lost time writing it before realizing foundry was just broken :/).
The snakecharmers blog post does a great job explaining EIP-7702 at both a high level and a low level, and also how to concretely implement it using web3.py, which is also used for the solve script here.

The attack flow is as follows:

1. Deploy a malicious Exploit.sol that implements the vcnkCompatibleReceiver interface
2. In its deliverEnergy(uint256 amount) callback, check the plant’s remaining capacity and recursively call requestPowerDelivery(amount, attackerEOA) again until the ControlUnit capacity is below the FAILSAFE_THRESHOLD
3. Sign a delegation authorization (type 4 TX) against your EOA using sign_authorization web3.py method
4. Register the malicious contract as a gateway
5. Call requestQuotaIncrease function to increase the quota of the malicious gateway to 10 ETH
6. Call requestPowerDelivery with the maximum amount (10 ETH) to trigger the reentrancy exploit

The full exploitation script is available here.

HTB{Pectra_UpGr4d3_c4uSed_4_sp3cTraL_bL@cK0Ut_1n_V0LnaYa}
